Máy cắt tiêu bản tự động YD-335AT hãng Jinhua YIDI Medical

Hãng sản xuất: Jinhua YIDI Medical Model: YD-335AT

Call: 0903.07.1102

Mô tả :

Section thickness range: 0.5- 100μm
Setting values :
From 0.5-2μm in 0.5μm –increments
Form 2-10μm in 1μm -increments
Form 10-20μm in 2μm -increments
Form 20-50μm in 5μm -increments
Form 50-100μm in 10μm increments

Chi tiết sản phẩm
Đánh giá sản phẩm
Thẻ tags

Máy cắt tiêu bản tự động

Model: YD-335AT

Hãng sản xuất: Jinhua YIDI Medical

Xuất xứ: Trung Quốc

Sản phẩm đặt tiêu chuẩn CE, chứng nhận ISO 9001

The Fully Automatic Microtome YD-355AT provides utmost reliability, user benefit and outstanding operator comfort. Great basic stability and precision, make this microtome a real multi-purpose instrument that meets the requirements both in paraffin and hard sectioning techniques of the biological, medical and industrial lab
Product specifications :
Fully automatic or manual model，Its two-in-one design concept, which allows motorized and manual sectioning, provides reproducible high-quality sections.
Adopted Germany stepper Motor and motor drive ensure slice more precisely ,more reliable and quiet.
The touch screen shows slice and trimming thickness ,section counter ,mode
and speed, stroke distance
Special function of specimen retraction which avoid the damage due to the
attrition between sample and the back of knife so that the sectioning is more smooth and the life of the knife is more longer .
Model of Blade Carrier for High or Lower Disposable Blades
The hand wheel can be locked in any position to ensure the sectioning as safe and convenient as possible
The waste tray can be disassembled easily
Safety alarm system , overload protection function, sleep mode protection
Universal cassette clamp and standard specimen clamp
Optional Blade carrier which can use Steel Knife or Blade Holder
Emergency stop
Foot Switch to control the Section
Easy operation with Separated Control Panel
Protection Guard
Remote control panel set trimming or section thickness , stroke ,cutting speed
Precise orientation of specimen clamp

Technical Data

Section thickness range: 0.5- 100μm
Setting values :
From 0.5-2μm in 0.5μm –increments
Form 2-10μm in 1μm -increments
Form 10-20μm in 2μm -increments
Form 20-50μm in 5μm -increments
Form 50-100μm in 10μm increments
Trimming section thickness range :5-500μm (600 /999μm is optional customization)
Cutting speed 0 – 300mm/s（0-400 or 500mm/s is optional customization）
Horizontal specimen stroke :20 mm(28mm is optional customization)
Vertical specimen stroke : 60mm(70mm is optional customization)
Specimen retraction :12μm (Specimen retraction from 0-220um/turn on or off is optional customization )
Specimen feed speed 1250/s (click) ,2000μm/s(keep pressing) . (forward and reverse with 3 speed is optional customization,3 different speed is( 500μm/s or 1000μm/s or2000μm/s)
Sample orientation:8°along the X-Y-axis,rotate 360°
Precision error: ± 5%
Maximum section size: 50 × 45mm
Voltage and power : 220v / 50Hz or 110 v /60Hz
Net weight：35kg
Dimensions incl. tray (L/T/H)：500mm（L）X320mm（W）X500mm（H）
